Video and Audio
Video and Audio
IP Video Input8-ch
HDMI Output4K(4096×2160)/30Hz,4K (3840×2160) /30Hz, 2K(2560×1440)/60Hz,1920×1080/60Hz,1600×1200/60Hz,1280×1024/60Hz,1280×720/60Hz
VGA Output1920*1080/60Hz,1280*1024/60Hz,1280*720/60Hz
Incoming Bandwidth80 Mbps
Outgoing Bandwidth80 Mbps
Audio Output1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio1-ch, RCA (2.0 Vp-p, 1kΩ)
Decoding
Decoding FormatH.265+,H.265,H.264+,H.264
Decoding Capability5 x1080P
Synchronous Playback8-ch
Recording Resolution8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Network
Network ProtocolTCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
Network Interface1 RJ-45 10 /100 Mbps self-adaptive Ethernet interface
PoE
InterfaceN/A
RAID
RAID TypeNo
Auxiliary Interface
SATA1
CapacityUp to 8TB capacity for each disk
USB Interface2 × USB 2.0
General
Power Supply12 VDC, 1.5 A
Consumption≤ 10 W
Working Temperature-10 to +55° C (14 to 131° F)
Working Humidity10 to 90 %
Chassis1U
Dimension (W × D × H)315 × 240 × 48 mm (12.4″ × 9.4″ × 1.9″)
≤ 1 kg (2.2 lb)
