Model DS-7608NI-Q2

Model DS-7608NI-Q2

Motion Detection 2.0
Human/Vehicle Analysis 4-ch

Video and Audio

IP Video Input 8-ch

Incoming Bandwidth 80 Mbps
Outgoing Bandwidth 80 Mbps
HDMI Output
1-ch, 4K (4096 x 2160)/30 Hz, 4K (3840 x 2160)/30 Hz, 2K (2560 x 1440)/60 Hz, 1920 x
1080/60 Hz, 1600 x 1200/60 Hz, 1280 x 1024/60 Hz, 1280 x 720/60 Hz
VGA Output 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
Video Output Mode HDMI/VGA simultaneous output
Audio Output 1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio 1-ch, RCA (2.0 Vp-p, 1 k Ω)

Decoding

Decoding Format H.265+,H.265,H.264+,H.264
Recording Resolution 8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
Synchronous Playback 8-ch
Decoding Capability 1-ch@8 MP (30 fps)/3-ch@4 MP (30 fps)/6-ch@1080p (30 fps)
Stream Type Video, Video & Audio
Audio Compression G.711ulaw/G.711alaw/G.722/G.726

Network

Remote Connection 32
Network Protocol
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP,
UPnP™, HTTP, HTTPS
Network Interface 1, RJ-45 10/100 Mbps self-adaptive Ethernet interface
Auxiliary Interface
SATA 2 SATA interfaces
Capacity Up to 8 TB capacity for each disk
Alarm In/Out N/A (4/1 is optional)
USB Interface 2 × USB 2.0

General

Power Supply 12 VDC, 3.33 A
Consumption ≤ 15 W (without HDD)
Working Temperature -10 °C to 55 °C (14 °F to 131 °F)
Working Humidity 10% to 90%
Chassis 1U chassis
Dimension (W × D × H) 385 × 315 × 52 mm (15.2″× 12.4″ × 2.0″)
Weight ≤ 1.8 kg (without HDD, 4.0 lb.)
Certification
FCC Part 15 Subpart B, ANSI C63.4-2014
CE EN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017
Certification
FCC Part 15 Subpart B, ANSI C63.4-2014
CE EN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017
