قیمت دوربین مداربسته 2 مگاپیکسلی هایک ویژن DS-2CD1023G0-IUF

Camera

Image Sensor 1/2.7″ Progressive Scan CMOS

Min. Illumination Color: 0.01 Lux @(F2.0, AGC ON), B/W: 0 Lux with IR

Shutter Speed 1/3 s to 1/100, 000 s

Slow Shutter Yes

Wide Dynamic Range Digital WDR

Day & Night IR cut filter

Angle Adjustment Pan: 0° to 360°, tilt: 0° to 180°, rotate: 0° to 360°

Lens

Focal Length & FOV

2.8 mm, horizontal FOV 112.1°, vertical FOV 60.0°, diagonal FOV 132.2°

4 mm, horizontal FOV 90.2°, vertical FOV 48.6°, diagonal FOV 107.6°

Lens Mount M12

Focus Fixed

Aperture F2.0

Illuminator

IR Wavelength 850 nm

IR Range Up to 30 m

Video

Max. Resolution 1920 × 1080

Main Stream

50 Hz: 25 fps (1920 × 1080, 1280 × 720)

60 Hz: 30 fps (1920 × 1080, 1280 × 720)

Sub-Stream

50 Hz: 25 fps (640 × 480, 640 × 360)

60 Hz: 30 fps (640 × 480, 640 × 360)

Video Compression

Main Stream: H.265/H.264

Sub-Stream: H.265/H.264/MJPEG

Video Bit Rate 32 Kbps to 8 Mbps

H.264 Type Baseline Profile/Main Profile/High Profile

H.265 Type Main Profile

H.264+ Main Stream supports

H.265+ Main Stream supports

Region of Interest (ROI) 1 fixed region for main stream

Audio

Audio Compression G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC

Audio Bit Rate

64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps

(MP2L2)/16 to 64 Kbps (AAC)

Audio Sampling Rate 8 kHz/16 kHz

Environment Noise Filtering Yes

Network

Protocols

TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™,

SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS

Simultaneous Live View Up to 6 channels

API Open Network Video Interface, ISAPI

User/Host Up to 32 users. 3 levels: administrator, operator and user

Network Storage MicroSD/SDHC/SDXC card (256 GB) local storage

Client iVMS-4200, Hik-Connect

Web Browser

Plug-in required live view: IE 10+

Plug-in free live view: Chrome 57.0+, Firefox 52.0+

Local service: Chrome 57.0+, Firefox 52.0+


Image Settings

Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client

software or web browser.

Day/Night Switch Day, Night, Auto, Schedule

Image Enhancement BLC, 3D DNR

Interface

Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port

On-Board Storage Built-in memory card slot, support microSD card, up to 256 GB

Built-in Microphone Yes

Hardware Reset Yes

Event

Basic Event Motion detection, video tampering alarm, exception

General

Linkage Method

Upload to FTP/memory card, notify surveillance center, send email, trigger recording,

trigger capture

Camera Material Metal & Plastic

Camera Dimension 177.6 mm × 66.2 mm × 67.8 mm (7.0″ × 2.6″ × 2.7″)

Package Dimension 216 mm × 121 mm × 118 mm (8.5″ × 4.8″ × 4.6″)

Camera Weight Approx. 270 g (0.6 lb.)

With Package Weight Approx. 490 g (1.1 lb.)

Storage Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)

Startup and Operating

Conditions

-30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)

Web Client Language English, Ukrainian

General Function

Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP

address filter

Firmware Version V5.5.120

Power Consumption and Current

12 VDC, 0.4 A, max. 5 W

PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.15 A, max. 6.5 W

Power Supply

12 VDC ± 25%

PoE: 802.3af, Class 3

Power Interface Ø 5.5 mm coaxial power plug

Approval

EMC

FCC SDoC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014,

EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC

VoC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)

Safety

UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);

CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); BIS (IS

13252(Part 1):2010+A1:2013+A2:2015)

Environment CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)

Protection IP67 (IEC 60529-2013)
