قیمت دی وی آر 4 کانال هایک ویژن مدل DS-7204HUHI-K1/P

Model DS-7204HUHI-K1/P   DS-7208HUHI-K2/P   DS-7216HUHI-K2/P

Recording

Video compression H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Encoding resolution
8 MP/5 MP/4 MP/3 MP/1080p/720p/WD1/4CIF/VGA/
CIF

Frame rate

Main stream:
8 MP@8fps/5 MP@12fps/4 MP@15fps/3 MP@18fps
1080p/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
*: 8 MP@8fps is only available for channel 1 of DS-7204HUHI-K1/P.
Sub-stream:
WD1/4CIF/CIF@25fps (P)/30fps (N)
Video bit rate 32 Kbps to 10 Mbps
Dual stream Support
Stream type Video, Video & Audio
Audio compression G.711u
Audio bit rate 64 Kbps
Video and Audio

IP video input

IP video input

4-ch (up to 8-ch) 8-ch (up to 16-ch) 16-ch (up to 32-ch)
Up to 8 MP resolution
*: The 8 MP signal input is only available for channel 1 of DS-7204HUHI-K1/P.
Support H.265+/H.265/H.264+/H.264 IP cameras
Analog video input
4-ch 8-ch 16-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
PoC camera input
Support Hikvision PoC camera

*: PoC access capability see Appendix.
HDTVI input 8 MP, 5 MP, 4 MP, 3 MP, 1080p30, 1080p25, 720p60, 720p50, 720p30, 720p25
AHD input 5 MP, 4 MP, 1080p25, 1080p30, 720p25, 720p30
HDCVI input 4 MP, 1080p25, 1080p30, 720p25, 720p30
CVBS input PAL/NTSC
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
HDMI/VGA output
1-ch,
2K (2560 × 1440)/60Hz,
1920 × 1080/60Hz,
1280 × 1024/60Hz,
1280 × 720/60Hz,
1024 × 768/60Hz
VGA: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 ×
720/60Hz, 1024 × 768/60Hz
HDMI: 1-ch, 4K (3840 × 2160)/30Hz,
2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 ×
1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Audio input 4-ch, RCA (2.0 Vp-p, 1 KΩ)
Audio output 1-ch, RCA (Linear, 1 KΩ)
Two-way audio 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
Synchronous playback 4-ch 8-ch 16-ch

Network

Network

Remote connections 32 64 128
Network protocols
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS,
ONVIF
Network interface
1,
RJ45 10M/100M
self-adaptive
Ethernet interface
1,
RJ45 10M/100M/1000M self-adaptive
Ethernet interface
Auxiliary interface
SATA 1 SATA interface 2 SATA interfaces
Capacity Up to 10 TB capacity for each disk
Serial interface RS-485 (half-duplex)
USB interface 2 × USB 2.0
Front panel: 1 × USB 2.0
Rear panel: 1 × USB 3.0
Alarm in/out 4/1 8/4 4/1

General

Power supply 48 VDC, 1 A 48 VDC, 1.8 A
100 to 240 VAC, 50 to 60 Hz,
2 A
Consumption
(without HDD)
≤ 40 W ≤ 60 W ≤ 140 W
Working temperature
-10 °C to +55 °C (+14 °F to
+131 °F)
Working humidity 10% to 90%
Dimensions (W × D ×
H)
315 × 242 × 45 mm (12.4
× 9.5 × 1.8 inch)
380 × 320 × 48 mm (15.0 × 12.6 × 1.9 inch)
Weights
(without HDD)
≤ 1.5 kg (3.3 lb) ≤ 2 kg (4.4 lb) ≤ 3.8 kg (8.4 lb)
