قیمت دوربین 2 مگاپیکسل هایلوک مدل PTZ-N4215-DE3

مشاهده مشخصات فنی دوربین مداربسته هایلوک مدل PTZ-N4215-DE3

Lens

FOVHorizontal field of view: 53.8° to 4.0° (wide-tele),Vertical field of view: 31.9° to 2.3° (wide-tele),Diagonal field of view: 60.4° to 4.6°(wide-tele)

Focal Length5 mm to 75 mm, 15× optical

Zoom SpeedApprox. 2.4 s (optical lens, wide-tele)

Working Distance10 mm to 1500 mm (wide-tele)

Aperture RangeF1.6 to F3.0

Smart Features

Basic Event DetectionMotion Detection, Video Tampering Detection, Exception Detection

Smart DetectionIntrusion Detection, Line Crossing Detection, Region Entrance Detection, Region Exiting Detection, Unattended Baggage Detection, Object Removal Detection

Smart RecordANR (Automatic Network Replenishment), Dual-VCA

ROIMain stream, sub-stream and third stream respectively support four fixed areas.

Network

Security MeasuresUser authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering

Network StorageBuilt-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB; NAS (NPS, SMB/ CIPS), ANR

ProtocolsIPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour

APIOpen-ended, support ONVIF, ISAPI, and CGI, support HIKVISION SDK and Third-Party Management Platform

Simultaneous Live ViewUp to 20 channels

User/HostUp to 32 users. ,3 levels: Administrator, Operator and User

ClientiVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect

Web BrowserIE 8 to 11, Chrome 31.0 to 44, Firefox 30.0 to 51


Image EnhancementHLC/BLC/3D DNR/Defog/EIS/Regional Exposure/Regional Focus

Sub-Stream50Hz: 25fps (704 × 576, 640 × 480, 352 × 288),60Hz: 30fps (704 × 480, 640 × 480, 352 × 240)

Max. Resolution1920 × 1080

Main Stream50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720),60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)

Third Stream50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288),60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)

Interface

Network Interface1 RJ45 10 M/100 M Ethernet Interface; PoE+ (802.3at, class4)

Camera Module

AGCAuto/Manual

Image Sensor1/2.8″ progressive scan CMOS

Min. IlluminationColor: 0.005 Lux @(F1.6, AGC ON),B/W: 0.001 Lux @(F1.6, AGC ON)

White BalanceAuto/Manual/ATW (Auto-Tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp

Shutter Time1/1 s to 1/30,000 s

Day & NightIR Cut Filter

Digital Zoom16×

Privacy Mask24 programmable privacy masks

Focus ModeAuto/Semi-automatic/Manual

WDR120 dB WDR

General

MaterialADC 12, PC, PMMA

DimensionsΦ165 mm × 168 mm (Φ 6.5″×6.6″) (In-ceiling mounting indoor model)

Approx. 2 kg (4.41 lb)

Protection LevelTVS 4000V Lightning Protection, Surge Protection and Voltage Transient Protection

Power

12 VDC, 2.0 A and PoE (802.3at), 42.5 to 57 VDC, 0.6 A, class4

Max.: 18 W

Working Temperature-10°C to 55°C (14°F to 131°F)

Working Humidity≤ 90%

PTZ

Movement Range (Pan)360° endless

Pan SpeedConfigurable, from 0.1°/s to 100°/s,Preset Speed: 100°/s

Movement Range (Tilt)From 0° to 90° (Auto-flip)

Tilt SpeedConfigurable, from 0.1°/s to 80°/s,Preset Speed: 80°/s

Proportional ZoomSupport

Presets300

Patrol Scan8 patrols, up to 32 presets for each patrol

Pattern Scan4 pattern scans, record time over 10 minutes for each scan

Power-Off MemorySupport

Park ActionPreset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan

PTZ Status DisplaySupport

Preset FreezingSupport

Scheduled TaskPreset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Dome Reboot/Dome Adjust

Compression Standard

H.264+Support

H.265+Support

H.264 TypeBaseline Profile/Main Profile/High Profile

Video CompressionMain Stream: H.265+/H.265/H.264+/H.264,Sub-Stream: H.265/H.264/MJPEG,Third Stream: H.265/H.264/MJPEG

H.265 TypeMain Profile

Video Bitrate32 Kbps to 16384 Kbps

SVCSupport
