Model DS-7104NI-Q1/M DS-7108NI-Q1/M

Model DS-7104NI-Q1/M DS-7108NI-Q1/M

Video and Audio

IP video input 4-ch 8-ch
Up to 4 MP resolution
Incoming bandwidth 40 Mbps 60 Mbps
Outgoing bandwidth 60 Mbps
HDMI output 1-ch, 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA output 1-ch, 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Video output mode HDMI/VGA simultaneous output

Decoding

Decoding format H.265+/H.265/ H.264+/H.264
Recording resolution 4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
Synchronous playback 4-ch
Capability 4-ch@1080p (25 fps), 2-ch@4 MP (25 fps)
Stream type Video, Video & Audio

Network

Network

Remote connection 16
Network protocol TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP,UPnP™
Network interface 1, RJ-45 10/100 Mbps self-adaptive Ethernet interface
Auxiliary interface
SATA 1 SATA interface
Capacity Up to 6 TB capacity for each disk
Alarm in/out N/A
USB interface Rear panel: 2 × USB 2.0

General

Power supply 12 VDC, 1.5 A
Consumption (without
HDD)
≤ 10 W
Working temperature -10 °C to 55 °C (14 °F to 131 °F)
Working humidity 10% to 90%
Dimension (W × D × H) 265 × 225 × 48 mm (10.4″ × 8.9″ × 1.9″)
Weight (without HDD) ≤ 1 kg (2.2 lb)
Certification
FCC Part 15 Subpart B, ANSI C63.4-2014
CE EN50130-4, EN 61000-3-2,EN 61000-3-3
