Camera

Image Sensor 1/2.8″ progressive scan CMOS
Min. Illumination Color: 0.01 Lux @(F1.2, AGC ON), 0.028Lux @ (F2.0, AGC ON)
Shutter Speed 1/3 s to 1/100, 000 s
Slow Shutter Yes
Auto-Iris No
Day &Night IR cut filter
Digital Noise Reduction 3D DNR
WDR Digital WDR
Angle Adjustment (Bracket) Pan: 0° to 360°, tilt: 0°to 180°, rotation: 0° to 360°

Lens

Focal length 2.8 mm, 4 mm, 6 mm
Aperture F2.0
Focus No
FOV
2.8 mm, horizontal FOV 103°, vertical FOV 59°, diagonal FOV 118°
4 mm, horizontal FOV 86°, vertical FOV 46°, diagonal FOV 102°
6 mm, horizontal FOV 54°, vertical FOV 30°, diagonal FOV 62°
Lens Mount M12

IR

IR Range Up to 30 m
Wavelength 850 nm

Compression Standard

Video Compression Main stream: H.265/H.264
Sub stream: H.265/H.264/MJPEG
H.264 Type Baseline Profile/Main Profile/High Profile
H.264+ Main stream supports
H.265 Type Main Profile
H.265+ Main stream supports
Video Bit Rate 32 Kbps to 8 Mbps
Smart Feature-set
Region of Interest 1 fixed region for main stream and sub-stream



Max. Resolution 1920 × 1080
Main Stream
Max. Frame Rate
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720)
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
Sub-stream
Max. Frame Rate
50Hz: 25fps (704 × 576, 640 × 480, 352 × 288)
60Hz: 30fps (704 × 480, 640 × 480, 352 × 240)
Image Enhancement BLC, 3D DNR
Image Setting Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or
web browser
Day/Night Switch Auto, scheduled

Network

Alarm Trigger Motion detection, video tampering alarm, illegal login
Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP,
802.1X, QoS, IPv6, UDP, Bonjour
General Function Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark
Firmware Version 5.5.2
Specification

Available Model

IPC-B120H (2.8 mm), IPC-B120H (4 mm), IPC-B120H (6 mm)
API ONVIF (PROFILE S, PROFILE G), ISAPI
Simultaneous Live View Up to 6 channels
User/Host
Up to 32 users
3 levels: Administrator, Operator, and User
Client iVMS-4200, Hik-Connect, iVMS-5200
Web Browser IIE7+, Chrome18-42, Firefox5.0+, Safari5.02+

Interface

Communication Interface 1 RJ45 10M/100M self-adaptive Ethernet port

General

Operating Conditions -30 °C to 50 °C (-22 °F to 122 °F), humidity: 95% or less (non-condensing)
Power Supply 12 VDC ± 25%, 5.5 mm coaxial power plug
PoE (802.3af, class 3)
Power Consumption and Current 12 VDC, 0.4 A, Max: 5 W
PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.13 A, Max: 7 W
Protection Level IP67
TVS 2000V lightning protection, surge protection and voltage transient protection
Material Metal & Plastic

Dimensions

Camera: Ø 70 mm × 191.3mm (Ø 2.7″ × 7.5″)
With package: 216 mm × 121 mm × 118 mm (8.5″ × 4.8″ × 4.6″)
Weight Camera: Approx. 280 g (0.62 lb.)
With package: Approx. 530 g (1.17 lb.)
