دوربین داهوا مدل DH-HAC-HDW1400TRQP-A

Camera

Image Sensor

1/2.7 inch CMOS

Max. Resolution

2560(H)×1440(V)

Pixel

4MP

Scanning System

Progressive

Electronic Shutter Speed

PAL: 1/25s–1/100000s
NTSC: 1/30s–1/100000s

S/N Ratio

>65dB

Min. Illumination

0.02Lux/F2.0 30IRE, 0Lux IR on

Illumination Distance

25m（82.0 ft）

IR On/Off Control

Auto; manual

Illuminator Number

2（IR）

Pan/Tilt/Rotation Range

Pan: 0°–360°
Tilt: 0°–78°
Rotation: 0°–360°

Lens

Lens Type

Fixed-focal

Mount Type

M12

Focal Length

2.8 mm; 3.6 mm

Max. Aperture

2.8mm: F2.0

3.6mm: F2.0

Field of View

2.8mm: H: 105°;V: 56°;D: 125°

3.6mm: H: 84°;V: 47°;D:104°

Iris Type

Fixed iris

Close Focus Distance

2.8mm: 0.7m(2.30 ft)

3.6mm: 1.1m(3.60 ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

2.8 mm

49.8m (163.4 ft)

19.9m

(65.3 ft)

10m

(32.8 ft)

5m

(16.4 ft)

3.6 mm

64m

(210.0 ft)

25.6m

(84 ft)

12.8m

(42 ft)

6.4m

(21 ft)

Video

Frame Rate

CVI:

PAL: 4M@25fps; 1080P@25fps;

NTSC: 4M@30fps; 1080P@30fps

AHD:

PAL: 4M@25fps;

NTSC: 4M@30fps

TVI:

PAL: 4M@25fps;

NTSC: 4M@30fps

CVBS:

PAL: 960H;

NTSC: 960H

Resolution

4M (2560 × 1440); 1080P (1920 × 1080); 960 H (960 × 576/960 × 480)

Day/Night

Auto switch by ICR

BLC

BLC/HLC/DWDR

WDR

DWDR

White Balance

Auto; manual

Gain Control

Auto; manual

Noise Reduction

2D NR

Smart IR

Yes

Mirror

Off/On

Privacy Masking

Off/On (8 area, rectangle)

Certifications

Certifications

Certifications

CE (EN55032:2015, EN 61000-3-2:2014, EN 61000-3-3:2013, EN55024:2010+A1:2015, EN 55035:2017, EN50130-4:2011+A1:2014)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1)

Port

Video Output

Video output choices of CVI/TVI/AHD/CVBS by one BNC port

Audio Interface

Built-in Mic (-A)

Power

Power Supply

12V ±30% DC

Power Consumption

Max 2.8W (12V DC, IR on)

Environment

Operating Temperature

-40°C to +50°C (-40°F to 122°F);<95% (non-condensation)

Storage Temperature

-40°C to +50°C (-40°F to 122°F);< 95% (non-condensation)

Protection Grade

IP50

Structure

Casing

Plastic

Dimensions

Φ97.1 mm × 93.0 mm (Φ3.82″ × 3.66″)

Net Weight

0.17 Kg (0.37lb))

Gross Weight

0.23 Kg (0.51lb)
