NVR 20ch

Input

• Video Input 20-ch
• Max Resolution 8MP
• Two-way Audio Input 1-ch, 3.5mm
• Bandwidth Income 120Mbps; Outgoing 100Mbps

Output

• HDMI/VGA Output HDMI 1-ch, 3840×2160, 2560×1440, 1920×1080, 1280×720, 1024×768, 1440×900, 1280×800VGA 1-ch, 1920×1080, 1280×720, 1024×768, 1440×900, 1280×800
• Screen Split 1/2/3/4/5/6/7/8/9/10/12/13/16/20A/20B
• Audio Output 1 RCA

Decoding

• Decoding Format S+265/H.265/H.264
• Recording Resolution 8MP/6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF
• Preview Capability 1 8MP, 1 6MP, 1 5MP, 2 4MP, 2 3MP, 4 1080P, 8 720P, 20 4CIF
• Synchronous Playback 1 8MP, 1 6MP, 1 5MP, 2 4MP, 2 3MP, 4 1080P, 8 720P
• Records Encryption Yes

Hard Disk

• SATA 2 SATA interfaces for 2 HDDs
• Capacity Up to 10TB for each HDD
• eSATA Interface N/A
• Array Type N/A

Network

• Protocol TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, IGMP, QoS, IPV4, IPV6, Multicast, ARP, UDP, SNMP, SSL, Telnet, RTMP, NFS
• System CompatibilityTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, IGMP, QoS, IPV4, IPV6, Multicast, ARP, UDP, SNMP, SSL, Telnet, RTMP, NFS

External Interface

• Network Interface 1xRJ45 self-adaptive 10/100/1000 Mbps network interface
• USB Interface 2xUSB 2.0
• Serial Interface N/A
• Alarm In/Out 4/1

General

• Web Version Web6
• Language Simple Chinese, Traditional Chinese, English, Spanish, Korean, Italian, Turkish, Russian, Thai, French, Polish, Dutch, Hebraism, Farsi, Arabic
• Operating Conditions -10 ～55 , 10%~90% RH
• Power Supply DC12V 3.33A
• Consumption (without HDD) 10W (without HDD)
• Chassis 1U
• Dimensions 47.1×272×341mm, (1.85×10.73×13.43 inch)
• Weight (without HDD) 1.6Kg (3.53lb)
